Products specifications

Category Development Boards, Kits, Programmers>Evaluation Boards - Audio Amplifiers
Mfr STMicroelectronics
Package Box
Product Status Obsolete
Amplifier Type Class D
Output Type 2-Channel (Stereo)
Max Output Power x Channels @ Load 2.5W x 2 @ 4Ohm
Voltage - Supply 2.5V ~ 5.5V
Board Type Fully Populated
Utilized IC / Part TS2012
Supplied Contents Board(s)
Other Names -497-8930,497-8930,STEVALCCA011V1
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8471.41.0150
Win Source Part Number 1284340-STEVAL-CCA011V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-CCA011V1 CAD Model

Description

STEVAL-CCA011V1 - Audio Power Amplifier Demonstration Board

The STEVAL-CCA011V1 from STMicroelectronics is a state-of-the-art demonstration board specifically designed for audio applications. It showcases the performance of the TDA7491LP dual BTL class-D audio amplifier which is capable of delivering high-quality sound while maintaining energy efficiency.

This demonstration board is a testament to STMicroelectronics' commitment to providing advanced solutions for audio amplification. With a wide supply voltage range from 8 V to 26 V, the STEVAL-CCA011V1 is versatile and can be used in a variety of audio systems, from small speakers to more demanding audio applications.

The TDA7491LP integrated in the STEVAL-CCA011V1 is designed to provide high output power, up to 2 x 10 W into 8 ohms, with excellent power efficiency. This makes it an ideal choice for battery-powered applications where power consumption is a critical factor. The amplifier also features low harmonic distortion and low noise levels, ensuring a clear and powerful audio experience.

The board comes equipped with a set of useful features such as standby and mute functions, which can be easily controlled via external signals. This allows for greater flexibility and power management in various audio system designs. Additionally, the TDA7491LP's advanced pop & click suppression ensures that the audio output is smooth and uninterrupted when powering on and off.

The compact size of the STEVAL-CCA011V1 makes it an excellent choice for space-constrained applications. Despite its small footprint, it does not compromise on performance, delivering rich and dynamic audio that can rival larger audio systems.

Overall, the STEVAL-CCA011V1 demonstration board is a powerful tool for developers and audio enthusiasts looking to explore the capabilities of the TDA7491LP audio amplifier. It provides a quick and easy way to evaluate the features and performance of the amplifier, simplifying the design process for audio systems.
