STMicroelectronics presents the STF5NK100Z, a robust N-channel Zener-protected SuperMESH™ Power MOSFET designed to deliver high performance in power switching applications. This advanced technology component is tailored for a diverse range of uses, including switch-mode power supplies, motor control, and power conversion systems.

Key Features

• High Voltage Capability: The STF5NK100Z is capable of handling a maximum voltage of 1000V, making it suitable for high voltage applications.
• Low On-Resistance: With an on-resistance of only 1.2 ohms, this MOSFET ensures high efficiency and low conduction losses.
• High Current Rating: The device can handle continuous drain currents up to 4.4A, allowing it to drive significant loads.
• Zener-Protected: The built-in Zener protection provides enhanced ruggedness and reliability, safeguarding the device from voltage transients.
• Reduced Gate Charge: The optimized gate charge minimizes switching losses, contributing to the overall efficiency of the system.
• 100% Avalanche Tested: Each unit is rigorously tested for avalanche performance, ensuring robustness in harsh conditions.

Applications

• Switch-mode power supplies (SMPS)
• High-efficiency DC-DC converters
• Motor control circuits
• Power inverters and converters
• Lighting applications

The STF5NK100Z is encapsulated in a TO-220FP package, which provides excellent thermal performance and is suitable for through-hole mounting, making it ideal for a wide variety of assembly techniques and design layouts. The combination of high voltage capability, low on-resistance, and Zener protection makes the STF5NK100Z an excellent choice for designers seeking a power MOSFET that balances performance with ruggedness.

For detailed specifications, technical documentation, and application support, visit STMicroelectronics' official website or contact their support team. The STF5NK100Z is a testament to STMicroelectronics' commitment to providing high-quality, reliable semiconductor products for advanced electronic applications.
