Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Series STripFET
Packaging Reel - TR
Part Status Obsolete(EOL)
Channel Type Type N
Technology MOSFET
Drain Source Voltage 75V
Current - Continuous Drain (Id) @ 25°C 20A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Vgs(th) (Maximum) @ Id 4V @ 250μA
Gate Charge (Qg) (Maximum) @ Vgs 53nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 3150pF @ 25V
Vgs (Maximum) ±20V
Power Dissipation (Maximum) 5.2W (Tc)
Rds On (Maximum) @ Id, Vgs 7 mOhm @ 10A, 10V
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting SMD
Manufacturer Package PolarPak
Package PolarPak
Win Source Part Number 1261130-STK20N75F3
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Limited
Family Name STK20N75F3
Introduction Date July 01, 2008
ECCN EAR99
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian STK20N75F3 CAD Model

Description

The STK20N75F3 is a high-performance N-channel Power MOSFET produced by STMicroelectronics, a global semiconductor leader known for its cutting-edge technology. This MOSFET is part of the MDmesh™ K3 series, which features a wide range of drain-source voltages, making them suitable for various applications, including switching regulators, power management, and high-efficiency DC-DC converters.

Key Features

  • High Voltage Capability: The STK20N75F3 is designed to handle a maximum drain-source voltage (V<sub>DS) of 750V, allowing it to be used in high voltage applications.
  • Low On-Resistance: With an R<sub>DS(on) value as low as 0.19 ohms, the device ensures minimal power loss and improved efficiency in electronic circuits.
  • High Current Capacity: This MOSFET can support a continuous drain current (I<sub>D) of up to 20A, making it a robust choice for high-power applications.
  • Reduced Gate Charge: The optimized gate charge (Q<sub>g) allows for faster switching speeds, which is crucial in power switching applications.
  • 100% Avalanche Tested: Each unit is guaranteed to withstand stress in avalanche and commutation modes, ensuring reliability and a longer lifespan.

Applications

The STK20N75F3 is versatile and can be used in a wide array of applications due to its robustness and high efficiency. Common applications include:

  • Switch Mode Power Supplies (SMPS)
  • LED Lighting
  • High-Efficiency DC/DC Converters
  • Motor Control Systems
  • Power Management Solutions

Package and Quality

The STK20N75F3 is available in a TO-220 package, which is widely used and suitable for through-hole mounting. This package ensures good thermal performance and is easy to handle during assembly processes. Additionally, STMicroelectronics commits to high-quality standards, with rigorous testing and quality control measures in place to ensure that each MOSFET meets the highest performance criteria.
