STL220N6F7 Power MOSFET by STMicroelectronics

The STL220N6F7 is a high-performance, N-channel Power MOSFET manufactured by STMicroelectronics, a global semiconductor leader known for its innovative and reliable products. This MOSFET is a part of the STripFET™ F7 series, which utilizes the latest advancements in silicon technology to offer improved power efficiency and thermal performance.

Key Features

• Voltage Rating: The STL220N6F7 boasts a robust drain-source voltage (V<sub>DS) of 60V, making it suitable for a wide range of applications that require efficient power regulation.
• Current Capacity: With a continuous drain current (I<sub>D) of 120A, this MOSFET can handle high current loads, ensuring reliable operation even under strenuous conditions.
• R<sub>DS(on) Values: The device offers ultra-low on-resistance (R<sub>DS(on)) values, which minimizes conduction losses and enhances overall efficiency.
• Gate Charge: A low gate charge (Q<sub>g) ensures that the STL220N6F7 can switch on and off rapidly, which is crucial for high-frequency applications and reduces switching losses.

Applications

The STL220N6F7 is designed to be versatile, catering to a broad spectrum of applications. It's particularly well-suited for:

• Switching regulators
• DC/DC converters
• Motor drivers
• Power management solutions
• Automotive applications

Package and Reliability

This MOSFET comes in an H2PAK-6 package, which is designed for high current applications and is characterized by its compact size and excellent thermal performance. The STL220N6F7 is also characterized by its high reliability and robustness, which are hallmarks of STMicroelectronics' products.

Environmental and Quality Standards

STMicroelectronics is committed to environmental sustainability. The STL220N6F7 is compliant with various environmental standards, including RoHS and Halogen-free specifications, ensuring that it meets global environmental directives. Additionally, the device adheres to the highest quality standards, with rigorous testing to guarantee performance under a wide range of conditions.
