Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 4A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 5V, 10V
Gate-Source Threshold Voltage 2.8V @ 250μA
Max Gate Charge 9nC @ 5V
Max Input Capacitance 340pF @ 25V
Maximum Gate-Source Voltage ±16V
Power Dissipation (Max) 3.3W (Tc)
Maximum Rds On at Id,Vgs 100 mOhm @ 1.5A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-223
Dimension TO-261-4, TO-261AA
Win Source Part Number 024695-STN3NF06
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Power Management, Industrial
Ultra Librarian 3D Model Ultra Librarian STN3NF06 CAD Model

Description

STN3NF06 - N-Channel MOSFET by STMicroelectronics

The STN3NF06 from STMicroelectronics is a high-performance N-Channel MOSFET designed for efficient power management in a variety of applications. This semiconductor device is known for its low on-resistance and high switching speed, making it a suitable choice for power supply designs, DC-DC converters, motor control circuits, and other power-intensive applications.

Key Features:

  • Voltage Rating: The STN3NF06 operates at a drain-source voltage (V<sub>DS) of 60V, which is ideal for systems that require moderate voltage levels.
  • Current Capacity: It is capable of handling continuous drain current (I<sub>D) up to 3A, ensuring reliable performance in high current scenarios.
  • Low R<sub>DS(on): With a low on-state resistance, typically around 0.07Ω, the device ensures minimal power loss and heat generation during operation.
  • High-Speed Switching: The fast switching capabilities of the STN3NF06 contribute to increased efficiency in applications requiring frequent on-off cycles.
  • Gate Charge: The MOSFET features a low gate charge, which reduces the power needed to turn the device on and off, further enhancing its overall efficiency.

Applications:

  • Switch Mode Power Supplies (SMPS)
  • DC-DC Converters
  • Motor Control Systems
  • Power Management Functions
  • Load Switching
  • Automotive and Industrial Applications

The STN3NF06 is presented in a TO-220 package, a widely used and robust package type that facilitates heat dissipation and allows for easy mounting on printed circuit boards. STMicroelectronics has designed this MOSFET with the quality and reliability that customers have come to expect from their products, ensuring that the STN3NF06 is a solid choice for your power management solutions.
