STP20N65M5 - N-channel 650 V, 0.19 Ohm typ., 20 A MDmesh™ M5 Power MOSFET in TO-220 Package

STMicroelectronics' STP20N65M5 is a state-of-the-art N-channel Power MOSFET designed with the innovative MDmesh™ M5 technology. This device is tailored for high efficiency in a wide range of applications, making it a perfect choice for designers looking for performance and reliability. The STP20N65M5 is a testament to STMicroelectronics' commitment to delivering advanced power conversion solutions.

Key Features

• High Voltage Rating: This MOSFET operates at a high voltage of 650V, making it suitable for various applications that require high voltage levels.
• Low On-Resistance: With a typical on-resistance of just 0.19 Ohm, the STP20N65M5 ensures minimal power loss and improved overall efficiency.
• High Current Capacity: It can handle a continuous current of 20A, which makes it robust for handling high power applications.
• Enhanced Switching Performance: The MDmesh™ M5 technology optimizes the device for fast switching, reducing switching losses and improving performance.
• Reduced Gate Charge: A lower gate charge allows for faster switching speeds and reduced driving power.
• TO-220 Package: The industry-standard TO-220 package provides a practical balance between performance and size, facilitating ease of integration into a variety of designs.

Applications

• Switch Mode Power Supplies (SMPS)
• LED Lighting
• High Performance Drives
• Welding Equipment
• Solar Inverters
• UPS Systems

The STP20N65M5 MOSFET is a versatile component that can be used in a diverse array of electronic circuits. Its high efficiency, combined with the robust package, makes it an ideal choice for power management tasks where reliability and energy savings are critical. Whether for industrial or consumer applications, the STP20N65M5 from STMicroelectronics is designed to deliver top performance, ensuring that your products are powered safely and efficiently.

For more detailed information about the STP20N65M5, including datasheets, technical documentation, and support, please visit the STMicroelectronics website or contact your local ST sales office.
