STMicroelectronics VN5E016AHTR-E Automotive-Grade Power MOSFET

The VN5E016AHTR-E is a high-performance automotive-grade power MOSFET from STMicroelectronics, designed to deliver efficient power management and control in a wide range of automotive applications. This robust component is part of STMicroelectronics' VIPower M0-5 family, renowned for its reliability and efficiency in harsh environments.

With an operating voltage range of 5.5V to 36V, the VN5E016AHTR-E is versatile enough to handle various automotive electrical systems. It is particularly suitable for driving resistive, inductive, and capacitive loads, making it an excellent choice for applications such as lamp drivers, heaters, DC motors, and other actuators in the automotive environment.

The VN5E016AHTR-E boasts an RDS(on) of just 16 mΩ at 25°C, which ensures minimal power loss and improved overall efficiency during operation. This low on-resistance is a critical feature for applications that require high current handling capabilities while maintaining low heat generation.

This power MOSFET is housed in a compact and robust PowerSSO-16 package, which offers excellent thermal performance and space-saving advantages on the PCB. The package is designed to meet the stringent requirements of the automotive industry, including resistance to shock, vibration, and temperature extremes.

One of the key features of the VN5E016AHTR-E is its built-in over-temperature protection. This safety feature helps prevent damage to the MOSFET and the surrounding components by shutting down the device if the junction temperature exceeds a predefined threshold. Additionally, the device includes current limitation, overvoltage clamp, and active VCC clamp, which contribute to the overall durability and longevity of the component in demanding automotive applications.

STMicroelectronics has also ensured that the VN5E016AHTR-E meets the necessary automotive qualification standards, including AEC-Q100, which certifies that this power MOSFET can reliably perform in automotive electronics systems. With its robust design, advanced protection features, and efficient power handling, the VN5E016AHTR-E is an excellent choice for designers looking to improve the reliability and performance of their automotive power management systems.
