The VNLD5160TR-E is a state-of-the-art, high-side driver manufactured by STMicroelectronics, a global semiconductor leader. This device is designed to deliver outstanding performance for driving inductive, resistive, or capacitive loads, with a particular emphasis on automotive and industrial applications where reliability and efficiency are paramount.

Key Features

• Integrated Power MOSFET: The VNLD5160TR-E incorporates a vertical current flow Power MOSFET with charge pump, enabling it to handle high current loads with ease.
• Diagnostic Functions: It comes equipped with comprehensive diagnostic features, including proportional load current sense, thermal shutdown, and under-voltage shutdown, ensuring safe and reliable operation.
• Wide Operating Voltage Range: The device operates over a wide voltage range from 5.5 V to 28 V, making it versatile for various applications.
• High-Side Switch: As a high-side switch, it allows for direct interfacing with the microcontroller, simplifying the control scheme.
• Protection Features: The VNLD5160TR-E includes overcurrent protection, over-temperature protection, and load dump protection, safeguarding the device and the load in adverse conditions.

Applications

The VNLD5160TR-E is ideal for a wide range of applications, particularly in the automotive sector, where it can be used for controlling various types of loads such as bulbs, LEDs, motors, and valves. Additionally, it is suitable for industrial automation systems, smart home applications, and any other system requiring a robust and reliable high-side driver.

Package and Quality

The VNLD5160TR-E is available in a compact and thermally efficient PowerSSO-16 package, which minimizes PCB space requirements while maximizing thermal performance. It is designed to meet the stringent quality standards of the automotive industry, complying with AEC-Q100 qualification, which ensures high reliability under harsh environmental conditions.

With its combination of features, protections, and applications, the VNLD5160TR-E from STMicroelectronics represents a versatile and robust solution for high-side driving needs in modern electronic systems.
