Same model may have multiple batches, images only for reference.
WPN3012HR47MT Sunlord
Same model may have multiple batches, images only for reference.

WPN3012HR47MT

Part No WPN3012HR47MT
Manufacturer Sunlord
Catalog Fixed Inductors
Description FIXED IND 470NH 3.9A 33MOHM SMD
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Shenzhen Sunlord Electronics Co., Ltd.
Series WPN
Package Tape & Reel
Product Status Active
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 470 nH
Tolerance ±20%
Current Rating (Amps) 3.9 A
Current - Saturation (Isat) 6.8A
Shielding Shielded
DC Resistance (DCR) 33mOhm Max
Q @ Freq -
Frequency - Self Resonant 86MHz
Ratings -
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 MHz
Features -
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package -
Size / Dimension 0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max) 0.047" (1.20mm)
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1370617-WPN3012HR47MT
Ultra Librarian 3D Model Ultra Librarian WPN3012HR47MT CAD Model

Description

The WPN3012HR47MT is a drum core, wirewound inductor manufactured by Shenzhen Sunlord Electronics Co., Ltd.

  • Mounting Type: Surface Mount
  • Package: Nonstandard
  • Size: 0.118" L x 0.118" W (3.00mm x 3.00mm)
  • Height: 0.047" (1.20mm)
  • Core Material: Ferrite
  • Inductance: 470 nH
  • Current Rating: 3.9 A
  • Shielded: Yes
  • DC Resistance (DCR): 33mOhm Max
  • Operating Temperature: -40°C to 125°C
  • Saturation Current: 6.8A
  • Product Status: Active
  • Tolerance: ±20%
  • Frequency of Self-Resonance: 86MHz
