The BZT52C36WS is a surface-mount Zener diode manufactured by TAITRON Components Incorporated. It is designed for voltage regulation and transient voltage suppression in various electronic circuits. This component is listed as END-OF-LIFE, potentially limiting its availability to existing stock.

Applications

• Voltage Regulation: Maintaining a stable voltage level in circuits.
• Transient Voltage Suppression (TVS): Protecting sensitive components from voltage spikes.
• Overvoltage Protection: Preventing damage from excessive voltage.
• Clipping Circuits: Limiting voltage levels to a specific range.
• Level Shifting: Adjusting voltage levels for different circuit sections.

Features

• Zener Diode: Provides a stable reverse breakdown voltage.
• Surface Mount Package: Compact size for automated assembly.
• Low Leakage Current: Minimizes power consumption.
• Precise Zener Voltage: Ensures accurate voltage regulation.
• High Surge Current Capability: Withstands transient voltage spikes.

Benefits

• Stable Voltage Regulation: Ensures consistent circuit performance.
• Effective Overvoltage Protection: Prevents damage to sensitive components.
• Compact Design: Saves valuable board space.
• Low Power Consumption: Improves energy efficiency.
• Reliable Performance: Provides stable operation in various conditions.

Additional Details

The BZT52C36WS is typically available in a SOD-323 surface-mount package. Its key electrical parameters include Zener voltage (Vz), reverse leakage current (Ir), and power dissipation (Pd). The Zener voltage is the specified reverse breakdown voltage, in this case, approximately 36V. The datasheet should be consulted for precise specifications and application recommendations. Due to its end-of-life status, replacement options may need to be considered for new designs.
