BZD27C11P Vaishali Semiconductor
Same model may have multiple batches, images only for reference.

BZD27C11P

Part No BZD27C11P
Manufacturer Taiwan Semiconductor
Catalog Diodes - Zener - Single
Description SUB SMA, 1000MW, 6%, ZENER DIODE
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr Taiwan Semiconductor
Package Tape & Reel
Product Status Active
Voltage - Zener (Nom) (Vz) 11 V
Tolerance ±5.45%
Power - Max 1 W
Impedance (Max) (Zzt) 7 Ohms
Current - Reverse Leakage @ Vr 4 µA @ 8.2 V
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 200 mA
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Surface Mount
Package / Case SOD-123
Supplier Device Package Sub SMA
Base Product Number BZD27
Standard Package 10,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0050
Win Source Part Number 574261-BZD27C11P
Ultra Librarian 3D Model Ultra Librarian BZD27C11P CAD Model

Description

The 574261-BZD27C11P is a single zener diode from the BZD27 series.

  • Package: Tape and reel
  • Standard Package Quantity: 10,000 pieces
  • Tolerance: ±5.45%
  • Power Rating: 1W
  • Forward Voltage (Vf): 1.2V @ 200mA
  • Reverse Leakage Current (Vr): 4μA @ 8.2V
  • Zener Voltage (Vz): 11V
  • Impedance (Zzt): 7 Ohms
  • Mounting Type: Surface mountable
  • Package/Case Type: SOD-123
  • Manufacturer: Taiwan Semiconductor
