Same model may have multiple batches, images only for reference.
BZD27C47P Vaishali Semiconductor
Same model may have multiple batches, images only for reference.

BZD27C47P

Part No BZD27C47P
Manufacturer Taiwan Semiconductor
Catalog Diodes - Zener - Single
Description SUB SMA, 1000MW, 6%, ZENER DIODE
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr Taiwan Semiconductor
Package Tape & Reel
Product Status Active
Voltage - Zener (Nom) (Vz) 47 V
Tolerance ±6.38%
Power - Max 1 W
Impedance (Max) (Zzt) 45 Ohms
Current - Reverse Leakage @ Vr 1 µA @ 36 V
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 200 mA
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Surface Mount
Package / Case SOD-123
Supplier Device Package Sub SMA
Base Product Number BZD27
Standard Package 10,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0050
Win Source Part Number 574308-BZD27C47P
Ultra Librarian 3D Model Ultra Librarian BZD27C47P CAD Model

Description

The BZD27C47P is a single Zener diode designed for discrete semiconductor applications.

  • Mounting: Surface mount
  • Package: SOD-123
  • Power Rating: 1W
  • Voltage Rating: 47V
  • Tolerance: ±6.38%
  • Impedance: 45 Ohms
  • Temperature Range: -55°C to 175°C
  • Performance: Reliable and high-performance
  • Regulation: Accurate voltage regulation
