Same model may have multiple batches, images only for reference.

ACH32C-222-T001

Name: ACH32C-222-T001
Brand: TDK Corporation
SKU: 426011
Availability: InStock
Rating: 4.85 (24 reviews)

Get a Quote

Part No	ACH32C-222-T001
Manufacturer	TDK Corporation
Catalog	EMI/RFI Filters (LC, RC Networks)
Description	FILTER LC(T) 2200PF SMD
Datasheet	ACH32C-222-T001 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Filters
Manufacturer	TDK Corporation
Packaging	Reel - TR
Status	Active
Type	Low Pass
Filter Order	3rd
Technology	LC (T-Type)
Number of Channels	1
Attenuation Value	-25dB @ 55MHz to 300MHz
Resistance - Channel (Ohms)	0.002
Current	6A
Values	C = 2200pF
ESD Protection	No
Temperature Range - Operating	-40°C to 125°C
Applications	General Purpose
Voltage Rating	50V
Mounting	SMD (SMT)
Dimension	0.126" L x 0.063" W (3.20mm x 1.60mm)
Height	0.091" (2.30mm)
Win Source Part Number	1011597-ACH32C-222-T001
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	ACH
Introduction Date	January 01, 2000
ECCN	EAR99
Country of Origin	Japan
Halogen Free	Unknown
Estimated EOL Date	Obsolete
Quantity per package	2k pcs
Ultra Librarian 3D Model	Ultra Librarian ACH32C-222-T001 CAD Model

Alternative Products

Description

The TDK Corporation ACH32C-222-T001 is a low pass LC (T-Type) filter with a 2200pF value.

Value: 2200pF
Height: 0.091" (2.30mm)
Current Rating: 6A
Filter Order: third-order
Attenuation: -25dB @ 55MHz to 300MHz
Application: widely used in filters
Production Status: currently in active production status.
Temperature Range: -40°C to 125°C
Packaging: reel
Supply and Demand Status: limited
Package Quantity: 2k pcs.
