The CKCA43C0G1H471KT010N is a leaded ceramic capacitor produced by TDK Corporation. It features a capacitance of 470 pF, a voltage rating of 50V, and utilizes a C0G (NP0) dielectric. This capacitor is designed for applications demanding high stability and minimal loss, particularly in high-frequency circuits and precision timing applications.

Applications

• Radio Frequency (RF) Circuits: Essential for tuning, filtering, and impedance matching in radio transmitters and receivers.
• Oscillators: Used in crystal oscillators and other timing circuits where frequency stability is crucial.
• Filters: Implemented in low-pass, high-pass, and band-pass filters for signal conditioning.
• Sensors: Employed in sensor circuits that require stable and accurate capacitance values for reliable measurements.
• Test and Measurement Equipment: Used in calibration standards and precision measurement instruments.

Features

• Capacitance of 470 pF: Provides a specific capacitance value suitable for various circuit designs.
• Voltage Rating of 50V: Can safely operate in circuits with voltage levels up to 50V.
• C0G (NP0) Dielectric: Exhibits excellent capacitance stability over a wide range of temperatures and voltages.
• Leaded Configuration: Facilitates easy through-hole mounting on printed circuit boards (PCBs).
• Low Dissipation Factor: Minimizes energy loss within the capacitor, improving circuit efficiency.

Benefits

• Superior Stability: The C0G dielectric ensures minimal capacitance drift with temperature and voltage changes.
• Reduced Energy Loss: The low dissipation factor contributes to higher circuit efficiency.
• Enhanced Reliability: The ceramic construction provides long-term reliability and consistent performance.
• Simple Installation: The leaded design allows for easy and secure mounting on PCBs.
• Improved Accuracy: The stable capacitance value ensures greater accuracy in sensitive circuits.

Additional Details

The CKCA43C0G1H471KT010N typically features a capacitance tolerance of ±10%. The leads are designed for easy soldering and reliable connection to the PCB. This capacitor is also RoHS compliant, meaning it meets environmental standards for hazardous substance restrictions. Consult the TDK datasheet for detailed technical specifications, including dimensions, operating temperature range, and soldering guidelines.
