MLF2012DR82KT Real Image MLF2012DR82KT label picture
Same model may have multiple batches, images only for reference.
MLF2012DR82KT Real Image MLF2012DR82KT label picture
MLF2012DR82KT Real Image MLF2012DR82KT label picture
Same model may have multiple batches, images only for reference.

MLF2012DR82KT

Part No MLF2012DR82KT
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description Inductors for Standard Circuits Multilayer/STD magnetic shielded MLF series | FIXED IND 820NH 150MA 650 MOHM
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer TDK Corporation
Packaging Tape and Reel
Type Multilayer
Material - Core Ferrite
Inductance 820nH
Tolerance ±10%
Current Rating (Amps) 150mA
Shielding Shielded
DC Resistance (DCR) 650mOhm Max
Q at Freq 25 at 25MHz
Frequency - Self Resonant 130MHz
Temperature Range - Operating -55°C ~ 125°C
Inductance Frequency - Test 25MHz
Mounting Style SMD
Manufacturer Package 0805
Supplier Device Package 0805
Parts Dimension 0.079" L x 0.049" W (2.00mm x 1.25mm)
Height - Seated (Maximum) 0.057" (1.45mm)
Manufacturer Pack Quantity 2,000
MSL Level 1 (Unlimited)
Win Source Part Number 1224252-MLF2012DR82KT
Manufacturer Homepage www.tdk.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MLF2012DR82KT CAD Model

Description

The TDK Corporation MLF2012DR82KT is a multilayer inductor with a shielding feature.

  • Inductance: 820nH
  • Tolerance: ±10%
  • Material: Ferrite
  • Frequency Self-Resonant: 130MHz
  • Supply and Demand Status: Balanced
  • Packaging: Tape and reel
  • Manufacturer Pack Quantity: 2,000
  • Compliance: ROHS3
