ZJYS81R5-2P24T-G01

Name: ZJYS81R5-2P24T-G01
Brand: TDK Corporation
SKU: 412601
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	ZJYS81R5-2P24T-G01
Manufacturer	TDK Corporation
Catalog	Common Mode Chokes
Description	Common Mode Chokes Dual 23.5uH 1kOhm 1MHz 0.5A 0.15Ohm DCR SMD Automotive T/R / CMC 500MA 2LN 1KOHM SMD AEC-Q200
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Filters
Manufacturer	TDK Corporation
Packaging	Reel - TR
Filter Type	Signal Line
Number of Lines	2
Impedance @ Frequency	1 kOhm @ 100MHz
Current Rating (Max)	500mA
DC Resistance (DCR) (Max)	150 mOhm
Voltage Rating - DC	80V
Temperature Range - Operating	-40°C to 125°C
Ratings	AEC-Q200
Mounting	SMD (SMT)
Height (Max)	0.197" (5.00mm)
Dimension	Horizontal, 4 Gull Wing
Win Source Part Number	091710-ZJYS81R5-2P24T-G01
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Automotive
Family Name	ZJYS
Introduction Date	July 26, 2001
ECCN	EAR99
Country of Origin	China, Germany
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian ZJYS81R5-2P24T-G01 CAD Model

Alternative Products

Description

The supply and demand status is sufficient.

Component Type: Signal line filter
Lines: 2 lines
Impedance @ Frequency: 1 kOhm @ 100MHz frequency
DC Resistance (Max): 150 mOhm
Rated: AEC-Q200
Suitable For: Automotive applications
Dimension: Horizontal, 4 Gull Wing
