HWS50A-5/A

Part No HWS50A-5/A
Manufacturer TDK-Lambda Americas Inc.
Catalog Off - Board Modules
Description VSBU-120 Series 73 W Single Output 3.3 V Open Frame AC/DC Power Supply
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Approvals CE
Mounting SMD (SMT)
Case / Package 120
Current - Output 1 10 A
Depth 120 mm
Efficiency 84 %
Height 82.042 mm
Isolation Voltage 3 kV
Lead Free Yes
Length 119.888 mm
Max Current Rating 650 mA
Max Input Voltage 265 V
Max Input Voltage (AC) 265 V
Maximum Operating Temperature 70 °C
Max Output Current 10 A
Max Output Power 50 W
Max Output Voltage 6 V
Max Power Dissipation 50 W
Min Input Voltage 85 V
Min Input Voltage (AC) 85 V
Min Operating Temperature -10 °C
Min Output Voltage 4 V
Mount Chassis Mount
Nominal Output Voltage 5 V
Number of Outputs 1
Output Current 10 A
Output Power 50 W
Output Voltage 5 V
Power Rating 50 W
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Voltage - Output 1 5 V
Weight 280 g
Width 31.496 mm
Win Source Part Number 1063740-HWS50A-5/A
Categories Off-Board Modules
Manufacturer TDK-Lambda Americas Inc.
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian HWS50A-5/A CAD Model

Description

The TDK-Lambda Americas Inc. HWS50A-5/A is an off-board module for electronic components.

  • Power: 50 W
  • Isolation Voltage: 3 kV
  • Output: Single
  • Current: 10 A
  • Voltage: 5 V
  • Efficiency: 84%
  • Mounting: SMD (SMT)
  • Weight: 280 g
  • CE Approved: Yes
  • Maximum Operating Temperature: 70 °C
  • Lead-Free: Yes
  • RoHS Compliant: Yes
  • Case/Package: 120
  • Alternative Parts: VSBU-120-3.3, HWS30A-5/A, HWS15A-5/A, HWS150A-5/A, S8VK-G12024, ECP180PS36, ECP180PS28HWS-50A-5/A, HWS-50A-5A, HWS50A-5/A., HWS50A-5A, HWS50A5/A, HWS50A5A
