1423967-1 Real Image
Same model may have multiple batches, images only for reference.

1423967-1

Part No 1423967-1
Manufacturer TE Connectivity
Catalog Signal Relays, Up to 2 Amps
Description Power Relay 24VDC 40A DPST-NO (( 68.58mm 36.34mm 51.05mm)) Flange Mount
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Ambient Temperature Range High 85 °C
Coil Current 68.57 mA
Coil Power 1.7 W
Coil Resistance 350 Ω
Coil Type Non-Latching
Coil Voltage (DC) 24 V
Contact Current Rating 30 A
Contact Material Cadmium, Silver
Current Rating 40 A
Height 51.05 mm
Length 68.58 mm
Maximum Operating Temperature 85 °C
Min Operating Temperature -55 °C
Number of Contacts 2
Number of Pins 6
Operate Time 25 ms
Packaging Bulk
RoHS Compliant
Schedule B 8536490075
Termination Screw
Throw Configuration DPST
Voltage Rating (AC) 600 V
Win Source Part Number 1035912-1423967-1
Categories Signal Relays,Up to 2 Amps
Manufacturer TE Connectivity
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 1423967-1 CAD Model

Description

The TE Connectivity is a high-quality signal relay that is perfect for use in various electronic devices.

  • Win Source Part Number: 1035912-1423967-1
  • Maximum Operating Temperature: 85 °C
  • Minimum Operating Temperature: -55 °C
