1825057-4

Name: 1825057-4
Brand: TE Connectivity
SKU: 972780
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	1825057-4
Manufacturer	TE Connectivity
Catalog	DIP Switches
Description	SWITCH SLIDE DIP SPST 100MA 24V / Dip Switch SPST 5 Position Through Hole Slide (Standard) Actuator 100mA 24VDC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Switches>DIP Switches
Mfr	TE Connectivity ALCOSWITCH Switches
Series	ADE
Package	Tube
Circuit	SPST
Number of Positions	5
Current Rating (Amps)	100mA
Voltage Rating	24VDC
Actuator Type	Slide (Standard)
Actuator Level	Raised
Contact Material	Copper Alloy
Contact Finish	Gold
Height Above Board	0.228" (5.80mm)
Mounting Type	Through Hole
Termination Style	PC Pin
Pitch	0.100" (2.54mm), Full
Washable	Yes
Temperature Range - Operating	-30°C ~ 85°C
Body Material	Polyphenylene Sulfide (PPS)
Length	0.578" (14.68mm)
Mechanical Life	1,000 Cycles
Electrical Life	1,000 Cycles
Base Product Number	1825057
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.50.9065
Other Names	ADE0504
Standard Package	30
Win Source Part Number	972780-1825057-4
Ultra Librarian 3D Model	Ultra Librarian 1825057-4 CAD Model

Alternative Products

Description

The TE Connectivity ALCOSWITCH Switches ADE0504 is a DIP switch that is designed to offer high performance and reliability for various applications.

Positions: 5
Pitch: 0.100" (2.54mm)
Termination Style: Full PC pin
Voltage Rating: 24VDC
Washable: Yes
Actuator Level: Raised
Mounting: Through-hole
Circuit: SPST
ROHS3 Compliant: Yes
