1825058-7 Real Image
Same model may have multiple batches, images only for reference.

1825058-7

Part No 1825058-7
Manufacturer TE Connectivity
Catalog DIP Switches
Description SWITCH SLIDE DIP SPST 100MA 24V  /  Dip Switch SPST 4 Position Surface Mount Slide (Standard) Actuator 100mA 24VDC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>DIP Switches
Mfr TE Connectivity ALCOSWITCH Switches
Series ADE
Package Tube
Circuit SPST
Number of Positions 4
Current Rating (Amps) 100mA
Voltage Rating 24VDC
Actuator Type Slide (Standard)
Actuator Level Raised
Contact Material Copper Alloy
Contact Finish Gold
Height Above Board 0.217" (5.50mm)
Mounting SMD (SMT)
Termination Style Gull Wing
Pitch 0.100" (2.54mm), Full
Washable Yes
Temperature Range - Operating -30°C ~ 85°C
Body Material Polyphenylene Sulfide (PPS)
Length 0.478" (12.14mm)
Mechanical Life 1,000 Cycles
Electrical Life 1,000 Cycles
Base Product Number 1825058
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9065
Other Names 1825058-7-ND,-1825058-7-SI,450-2040,-ADE04S04-SI-ND,-ADE04S04-SI
Standard Package 35
Win Source Part Number 1035081-1825058-7
Ultra Librarian 3D Model Ultra Librarian 1825058-7 CAD Model

Description

The ADE series DIP switch is a surface mount device with a pitch of 0.100 inches and a full termination style of gull wing.

  • Positions: 4
  • Circuit: SPST
  • Actuator Type: Slide (standard)
  • Actuator Level: Raised
  • Washable: Yes
  • Mechanical Life: 1,000 cycles
  • Electrical Life: 1,000 cycles
  • Contact Material: Copper alloy
  • Contact Finish: Gold
  • Voltage Rating: 24VDC
  • Body Material: Polyphenylene Sulfide (PPS)
  • Height above the board: 0.217 inches
  • Length: 0.478 inches
  • Package: Tube
  • Temperature Range: -30°C to 85°C
  • Cross-reference: 1-1825059-3, 1-1825059-7, SD04H1SB, 2-1825059-4, 219-4MSTR, 219-4MST, 218-4LPSJF, SDA04H1SBD, and BPA04SKR1825058-7
