The AMPMODU Mod II series from TE Connectivity AMP Connectors is a header, breakaway type connector that comes in tube packaging. The manufacturer of this product is TE Connectivity AMP Connectors.

• Series: AMPMODU Mod II
• Positions: 14
• Current: 3A
• Voltage: 30VAC
• Connector Type: Male pin
• Positions Loaded: All
• Rows: 2
• Termination: Through solder
• Fastening Type: Push-pull
• Contact Material: Copper alloy
• Insulation Material: Liquid crystal polymer (LCP)
• Connector Style: Board to board or cable
• Pitch-Mating: 0.100" (2.54mm)
• Contact Finish-Mating: Gold
• Contact Finish Thickness-Mating: 30μin (0.76μm)
• Contact Finish-Post: Tin
• Contact Finish Thickness-Post: 100μin (2.54μm)
• Family Name: 146130
• Categories: Connectors, Interconnects
• Shrouding: Unshrouded
• Row Spacing-Mating: 0.100" (2.54mm)
• Height: 0.090" (2.29mm)
• Contact Shape: Square
• Contact Length-Mating: 0.230" (5.84mm)
• Alternative Parts: A-TSM-107-02-T-DV, TSM-107-02-T-DV-A-TR, TSM-107-02-TM-DV-A-001
• Introduction Date: November 25, 2002
• Estimated EOL Date: 2026
• ECCN: EAR99
• Halogen-Free: Yes
• Supply and Demand Status: Limited
