The 535632-1 is a crimp snap-in pin contact from TE Connectivity's MATE-N-LOK series. These contacts are designed for reliable and durable wire-to-board and wire-to-wire connections.

Applications:

• Power supplies
• Appliances
• Industrial equipment
• Automotive applications (specifically for lower-power or signal connections)
• Lighting systems

Features:

• Crimp termination for secure wire connection.
• Snap-in design for easy installation and removal from connector housings.
• Tin plating for corrosion resistance and improved solderability.
• Suitable for a range of wire sizes.
• Durable construction for long-lasting performance.

Benefits:

• Provides a reliable and secure electrical connection.
• Simplifies assembly and maintenance processes due to the snap-in feature.
• Reduces the risk of corrosion, ensuring long-term reliability.
• Versatile, supporting various wire gauges for different application needs.
• Contributes to the overall durability and longevity of the connected system.

Additional Details:

The 535632-1 contact is typically used with MATE-N-LOK connector housings. It is designed to accept a specific range of wire gauges, usually indicated in AWG (American Wire Gauge). The tin plating provides excellent corrosion resistance, which is essential for maintaining a stable connection in harsh environments. The crimp termination ensures a gas-tight seal between the wire and the contact, preventing oxidation and maintaining electrical conductivity. For optimal performance, it's crucial to use the correct crimping tool as specified by TE Connectivity. This ensures that the crimp is properly formed and that the wire is securely held in place. The snap-in feature of the contact allows for easy insertion and removal from the connector housing, simplifying assembly and maintenance. The MATE-N-LOK system is a widely used and trusted connection system, known for its reliability and ease of use. The 535632-1 contact is an integral part of this system, providing a secure and dependable connection for a variety of applications.
