9-1415536-1 Real Image
Same model may have multiple batches, images only for reference.

9-1415536-1

Part No 9-1415536-1
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE DPDT 6A 24V / General Purpose Relay DPDT (2 Form C) 24VDC Coil DIN Rail
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays>Power Relays, Over 2 Amps
Mfr TE Connectivity Potter & Brumfield Relays
Series SR2Z, SCHRACK
Package Bulk
Mounting Type DIN Rail
Coil Voltage 24VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 6 A
Switching Voltage 250VAC - Max
Coil Current 29.2 mA
Coil Type Non Latching
Features Socket Included
Termination Style Spring Terminal
Must Operate Voltage 21.6 VDC
Must Release Voltage 2.4 VDC
Temperature Range - Operating -25°C ~ 50°C
Contact Material Silver Nickel (AgNi)
Relay Type General Purpose
Coil Resistance 822 Ohms
Base Product Number 9-1415536
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.41.0020
Other Names SR2ZY024,-9-1415536-1-SI,9-1415536-1-ND,-SR2ZY024-SI-ND,2266-9-1415536-1,PB2248,SR2ZY024-ND,-SR2ZY024-SI
Standard Package 5
Win Source Part Number 1095897-9-1415536-1
Ultra Librarian 3D Model Ultra Librarian 9-1415536-1 CAD Model

Description

This SCHRACK electronic component is a DPDT power relay with a coil voltage of 24VDC.

  • Termination Style: Spring Terminal
  • Contact Material: Silver Nickel (AgNi)
  • Coil Resistance: 822 Ohms
  • Coil Current: 29.2 mA
  • Contact Rating (Current): 6 A
  • Switching Voltage: 250VAC - Max
  • Mounting: DIN Rail Mounted
  • Temperature Range: -25°C to 50°C
