ADC128S052QCMT/NOPB

Part No ADC128S052QCMT/NOPB
Manufacturer Texas Instruments
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description IC ADC 12BIT SAR 16TSSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Data Acquisition - Analog to Digital Converters (ADC)
Mfr Texas Instruments
Series Automotive, AEC-Q100
Package Tube
Product Status Active
Number of Bits 12
Sampling Rate (Per Second) 500k
Number of Inputs 8
Input Type Single Ended
Data Interface SPI, DSP
Configuration MUX-S/H-ADC
Number of A/D Converters 1
Architecture SAR
Reference Type Supply
Voltage - Supply, Analog 2.7V ~ 5.25V
Voltage - Supply, Digital 2.7V ~ 5.25V
Temperature Range - Operating -40°C ~ 125°C
Package / Case 16-TSSOP (0.173", 4.40mm Width)
Supplier Device Package 16-TSSOP
Mounting Type Surface Mount
Base Product Number ADC128
Standard Package 92 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 847734-ADC128S052QCMT/NOPB
Ultra Librarian 3D Model Ultra Librarian ADC128S052QCMT/NOPB CAD Model

Description

The ADC128S052QCMT/NOPB is a high-performance, low-power, 12-bit analog-to-digital converter (ADC) from Texas Instruments. This device is designed to deliver exceptional accuracy and speed, making it an ideal solution for a wide range of applications, including data acquisition systems, industrial control, medical instrumentation, and communication systems.

Key Features

  • Resolution: 12-bit resolution provides precise digital representation of analog signals.
  • Channels: Features 8 multiplexed channels, allowing multiple signal inputs with a single ADC.
  • Sampling Rate: Offers a fast sampling rate of up to 500 kilosamples per second (ksps), suitable for capturing rapidly changing signals.
  • Interface: The device includes a serial interface compatible with SPI, QSPI™, MICROWIRE™, and DSP interface standards, providing flexible integration options.
  • Supply Voltage: Operates on a single 2.7V to 5.25V supply, accommodating a variety of power environments.
  • Low Power Consumption: With a typical power consumption of only 15.5 mW at 3V, this ADC conserves energy, making it ideal for power-sensitive applications.
  • Package: Available in a 16-lead, QFN (WQFN) package, which is compact and space-efficient.
  • Temperature Range: The device operates over an industrial temperature range of -40°C to +105°C, ensuring reliability under extreme conditions.

Applications

  • Data Acquisition Systems
  • Industrial Control and Automation
  • Medical Instrumentation
  • Communication Systems

Quality and Reliability

The ADC128S052QCMT/NOPB is designed to meet the rigorous standards of Texas Instruments for quality and reliability. It features no lead (Pb) in its construction, adhering to environmentally responsible manufacturing practices. This ADC is a robust solution for designers who require high accuracy, multiple input channels, and low power consumption in their applications.
