The CD74HC08M96G4 is a high-performance, quad 2-input AND gate integrated circuit from Texas Instruments, renowned for its reliability and efficiency in digital logic operations. This IC is a part of the HC family, which signifies that it is fabricated using high-speed CMOS technology, ensuring low power consumption and a broad voltage operating range.

Key Features

• Logic Type: Quad 2-Input AND Gate – This IC contains four independent AND gates that can perform the logical AND function on two inputs each.
• Operating Voltage: 2V to 6V – The CD74HC08M96G4 is versatile, functioning effectively across a range of voltages, making it suitable for various applications.
• High-Speed Performance: The IC offers high-speed performance with a typical propagation delay of 8ns at a 5V supply, facilitating quick signal processing for efficient operations.
• Low Power Consumption: With CMOS technology, the device has a low power dissipation, which is ideal for battery-operated and power-sensitive applications.
• Output Drive Capability: The outputs can drive up to 10 LSTTL loads, providing sufficient current for interfacing with other logic families.
• Temperature Range: The CD74HC08M96G4 is designed to operate over a broad temperature range, typically from -55°C to 125°C, ensuring reliability across various environmental conditions.
• Packaging: It comes in an industry-standard SOIC-14 package, which is suitable for surface mounting and compatible with automated assembly processes.

Applications

The versatility of the CD74HC08M96G4 makes it an excellent choice for a wide array of applications, including:

• Logic function integration
• Signal gating
• Function generation
• Industrial electronics
• Consumer electronics
• Telecommunications
• Computing systems

Quality and Support

Texas Instruments is committed to providing high-quality products and support. The CD74HC08M96G4 is backed by TI's rigorous testing and validation processes, ensuring that customers receive reliable and consistent performance for their critical applications. Additionally, customers can access extensive technical documentation, design resources, and customer support to assist with their design and implementation needs.
