CD74HC4050M High-Speed CMOS Logic Hex Buffer and Line Driver

The CD74HC4050M is a high-speed CMOS logic hex buffer and line driver designed to interface with high-voltage input signals to low-voltage CMOS logic at data rates up to 10 Mbps. Manufactured by Texas Instruments, this device is part of their high-speed CMOS range that offers a blend of speed and robust performance.

Key Features:

• Logic Type: Buffer, Non-Inverting
• Number of Elements: Six
• Number of Bits per Element: One
• Input Voltage Range: 2V to 6V
• High-to-Low Level Logic Conversion: Makes it suitable for interfacing with high-voltage systems.
• Operating Temperature Range: -55°C to 125°C, suitable for various environmental conditions.
• Mounting Type: Surface Mount
• Package / Case: SOIC-16
• Propagation Delay Time: 165 ns at 2V, 40 ns at 4.5V, 33 ns at 6V

Applications:

The CD74HC4050M is ideal for a range of applications where logic level shifting is required, especially when interfacing between systems operating at different voltage levels. Common applications include:

• Logic level translation for microprocessors
• Memory interfacing
• Data acquisition systems
• Signal buffering

Quality and Reliability:

Texas Instruments is known for its commitment to quality and reliability, and the CD74HC4050M is no exception. Each device undergoes rigorous testing to ensure it meets the high standards expected for professional electronic components. The device is also supported by Texas Instruments' comprehensive technical resources, including datasheets, application notes, and design support.

Ordering Information:

The CD74HC4050M is available in tape and reel packaging, facilitating efficient assembly during the manufacturing process. For detailed ordering and shipping information, please refer to the Texas Instruments website or contact an authorized distributor.
