CSD17307Q5A Texas Instruments CSD17307Q5A Real Image CSD17307Q5A Real Image CSD17307Q5A real image 2 CSD17307Q5A label picture CSD17307Q5A label picture 2 CSD17307Q5A label picture 3
Same model may have multiple batches, images only for reference.
CSD17307Q5A Texas Instruments CSD17307Q5A Real Image CSD17307Q5A Real Image CSD17307Q5A real image 2 CSD17307Q5A label picture CSD17307Q5A label picture 2 CSD17307Q5A label picture 3
CSD17307Q5A Texas Instruments CSD17307Q5A Real Image CSD17307Q5A Real Image CSD17307Q5A real image 2 CSD17307Q5A label picture CSD17307Q5A label picture 2 CSD17307Q5A label picture 3
Same model may have multiple batches, images only for reference.

CSD17307Q5A

Part No CSD17307Q5A
Manufacturer Texas Instruments
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 30V 73A 8SON
Datasheet
CSD17307Q5A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 14A (Ta), 73A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 3V, 8V
Gate-Source Threshold Voltage 1.8V @ 250μA
Max Gate Charge 5.2nC @ 4.5V
Max Input Capacitance 700pF @ 15V
Maximum Gate-Source Voltage +10V, -8V
Power Dissipation (Max) 3W (Ta)
Maximum Rds On at Id,Vgs 10.5 mOhm @ 11A, 8V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-VSON (5x6)
Dimension 8-PowerTDFN
Win Source Part Number 013363-CSD17307Q5A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian CSD17307Q5A CAD Model

Description

CSD17307Q5A Description

The CSD17307Q5A is an advanced NexFET? Power MOSFET designed for optimal efficiency in switching applications. With its compact SON 5x6 package and high-performance features, it serves as an excellent choice for a variety of power management tasks.

Features and Benefits

  • Low RDS(on) for improved efficiency
  • Enhancement-mode transistor
  • Optimized for high-frequency applications
  • Lead-free, RoHS-compliant package

Applications

  • DC-DC converters
  • Load switches
  • Speed control systems for motors
  • Portable electronics

The CSD17307Q5A is notable for its robust build and efficiency-oriented design, making it an ideal component for engineers seeking reliable performance in compact systems.
