CSD18532Q5B

Part No CSD18532Q5B
Manufacturer Texas Instruments
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH Si 60V 100A 8-Pin VSON-CLIP EP T/R / MOSFET N-CH 60V 23A 8VSON
Datasheet
CSD18532Q5B Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 100A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.2V @ 250μA
Max Gate Charge 58nC @ 10V
Max Input Capacitance 5070pF @ 30V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3.2W (Ta), 156W (Tc)
Maximum Rds On at Id,Vgs 3.2 mOhm @ 25A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-VSON (5x6)
Dimension 8-PowerTDFN
Win Source Part Number 013374-CSD18532Q5B
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Power Management, Motor Drive & Control, Industrial
Family Name CSD18532Q5B
Introduction Date December 18, 2012
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian CSD18532Q5B CAD Model

Description

Product Description

The CSD18532Q5B is an advanced N-channel MOSFET known for its robust design and efficient power delivery. Its architecture supports a broad spectrum of electronics, ensuring versatile usage.

Applications

  • Power Inverters
  • Solar Power Systems
  • LED Lighting
  • High-Frequency Circuits

Features and Benefits

  • High Efficiency: Reduces system energy consumption.
  • Enhanced Durability: Complex environments handling with minimal wear.
  • Compact Design: Simplifies integration into space-constrained devices.

Additional Details

Manufactured to meet current industry standards, the CSD18532Q5B ensures rapid deployment in new and existing systems.
