Product Overview: DS26C31TM/NOPB

The DS26C31TM/NOPB is a robust, CMOS quad differential line driver designed for digital data transmission over balanced lines. Manufactured by Texas Instruments, this integrated circuit is part of their industry-leading line of interface products. The device conforms to the TIA/EIA-422-B and ITU-T V.11 standards, making it suitable for a wide range of applications in telecommunications, networking, and data acquisition systems.

Key Features

• Interface Type: Differential Line Driver
• Number of Drivers: 4
• Data Rate: High-speed operation
• Supply Voltage Range: 4.5V to 5.5V
• Output Current: 10 mA
• Power-Off Source Impedance: High
• Package: SOIC-16
• Temperature Range: -40°C to +85°C
• Lead-Free / RoHS Compliant: Yes
• Mounting Type: Surface Mount

Performance and Durability

The DS26C31TM/NOPB is built for reliable performance in challenging environments. It operates over a wide temperature range and is designed to withstand electrostatic discharge (ESD) events. Its tri-state outputs and high-impedance power-off mode ensure minimal power consumption and reduced line interference when the device is not in use or is powered down.

Applications

This line driver is ideal for long-distance and high-speed data communication applications. It can be used in:

• Point-to-Point and Multidrop Data Buses
• Digital Control Loops
• Industrial Control Networks
• Local Area Networks (LANs)
• RS-422, RS-423 Communication Interfaces

Quality and Environmental Compliance

The DS26C31TM/NOPB is a testament to Texas Instruments' commitment to quality and environmental sustainability. It is lead-free and RoHS compliant, ensuring that it meets the requirements for hazardous substance regulations. TI's rigorous testing and quality assurance processes ensure that this product delivers consistent performance and reliability.
