DS90UB914ATRHSJQ1

Part No DS90UB914ATRHSJQ1
Manufacturer Texas Instruments
Catalog Interface - Serializers, Deserializers
Description DS90UB913A-Q1/DS90UB914A-Q1 25 to100 MHz 10/12-Bit
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Series Automotive, AEC-Q100
Packaging Reel - TR
Function Deserializer
Data Rate 1.4Gbps
Input Type FPD-Link III, LVDS
Output Type LVCMOS
Number of Inputs 1
Number of Outputs 12
Operating Supply Voltage 1.71 V ~ 3.6 V
Operating Temperature Range -40°C ~ 105°C (TA)
Mounting SMD
Package 48-WFQFN Exposed Pad
Manufacturer Package 48-WQFN (7x7)
Win Source Part Number 1169657-DS90UB914ATRHSJQ1
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name DS90UB914A-Q1
Introduction Date June 14, 2013
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028

Description

The DS90UB914ATRHSJQ1 from Texas Instruments is a highly reliable automotive-grade serializer that is part of the FPD-Link III family, designed to transmit high-speed data from cameras and sensors to an electronic control unit (ECU) over a single differential cable. This component is specifically tailored for the demanding requirements of the automotive industry, delivering robust data communication with exceptional performance.

Key Features

  • High-Speed Data Transmission: Supports 25 to 100 MHz pixel clock for 10-bit or 12-bit pixel depth, enabling fast and efficient data transfer.
  • FPD-Link III Interface: Utilizes Texas Instruments' advanced FPD-Link III technology to ensure high-integrity serial data transmission with embedded clock over a single differential pair.
  • Adaptive Equalization: Features adaptive equalization to compensate for cable loss, enhancing signal integrity over long cable distances typical in automotive applications.
  • Backward Channel: Includes a bidirectional control channel that operates at 2 Mbps, allowing for configuration and control communication between the serializer and deserializer.
  • Automotive Qualification: Qualified for automotive applications, meeting stringent AEC-Q100 Grade 2 requirements for temperature and reliability.
  • EMI Reduction: Incorporates spread spectrum clocking and other features to minimize electromagnetic interference, a critical consideration in vehicle electronics.

Applications

The DS90UB914ATRHSJQ1 is ideal for a wide range of automotive applications, including:

  • Advanced Driver Assistance Systems (ADAS)
  • Rearview and surround-view camera systems
  • Driver monitoring systems
  • Automotive infotainment and display systems

Package and Availability

This serializer is available in a compact QFN package, making it suitable for space-constrained automotive environments. It is also designed for ease of use with a minimal external component count, reducing system complexity and cost.

With its robust design and advanced features, the DS90UB914ATRHSJQ1 is a critical component for developers looking to create sophisticated automotive systems that require high-speed, reliable data transmission in harsh vehicular environments.
