ISO7760FDWR Real Image ISO7760FDWR real image15655
Same model may have multiple batches, images only for reference.
ISO7760FDWR Real Image ISO7760FDWR real image15655
ISO7760FDWR Real Image ISO7760FDWR real image15655
Same model may have multiple batches, images only for reference.

ISO7760FDWR

Part No ISO7760FDWR
Manufacturer Texas Instruments
Catalog Digital Isolators
Description ISO7760FDW/R DIG ISO - MYNA - 6C / High-Speed, Robust EMC, Reinforced Six-Channel Digital Isolators
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Packaging Reel
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 6
Inputs - Side 1/Side 2 6/0
Channel Type Unidirectional
Voltage - Isolation 5000Vrms
Common Mode Transient Immunity (Min) 85kV/μs
Data Rate 100Mbps
Propagation Delay tpLH / tpHL (Maximum) 16ns, 16ns
Pulse Width Distortion (Maximum) 4.9ns
Rise / Fall Time (Typ) 1.1ns, 1.4ns
Supply Voltage (V) 2.25V ~ 5.5V
Temperature Range - Operating -55°C ~ 125°C
Mounting Style SMD
Manufacturer Package 16-SOIC
Supplier Device Package 16-SOIC
Manufacturer Pack Quantity 2,000
MSL Level 2 (1 Year)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 808042-ISO7760FDWR
Ultra Librarian 3D Model Ultra Librarian ISO7760FDWR CAD Model

Description

The Texas Instruments ISO7760FDWR is a six-channel, unidirectional digital isolator from Texas Instruments.

  • Data Rate: 100Mbps
  • Technology: Capacitive Coupling
  • Isolation Voltage: 5000Vrms
  • Supply Voltage: 2.25V to 5.5V
  • Rise/Fall Time: 1.1ns / 1.4ns
  • Common-Mode Transient Immunity: 85kV/μs
  • Propagation Delay: 16ns
  • Package: 16-SOIC
  • Temperature Range: -55°C to 125°C
  • Supply and Demand Status: Balanced
  • Manufacturer Pack Quantity: 2,000
  • MSL Level: 2 (1 Year)
