LM1085ISX-3.3 Real Image LM1085ISX-3.3 Real Image1 LM1085ISX-3.3 Real Image2
Same model may have multiple batches, images only for reference.
LM1085ISX-3.3 Real Image LM1085ISX-3.3 Real Image1 LM1085ISX-3.3 Real Image2
LM1085ISX-3.3 Real Image LM1085ISX-3.3 Real Image1 LM1085ISX-3.3 Real Image2
Same model may have multiple batches, images only for reference.

LM1085ISX-3.3

Part No LM1085ISX-3.3
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 3.3V 3A DDPAK
Datasheet
LM1085ISX-3.3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 27V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 1.5V @ 3A
Output Current 3A
Operating Supply Current 10mA
PSRR 72dB (120Hz)
Control Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 1.3V @ 3A
Mounting SMD (SMT)
Case / Package DDPAK/TO-263-3
Win Source Part Number 090348-LM1085ISX-3.3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name LM1085
Introduction Date July 01, 1999
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian LM1085ISX-3.3 CAD Model

Description

The LM1085ISX-3.3 is a high-performance, low-dropout voltage regulator product from Texas Instruments, a leading global semiconductor company.

  • Output Current: 3A
  • Regulated Voltage: 3.3V
  • Dropout Voltage: Low
  • Efficiency: High
  • Package: TO-263
  • Protection: Current limit and thermal shutdown features
