LM1117IMPX-3.3 Texas Instruments LM1117IMPX-3.3 Real Image LM1117IMPX-3.3 real image948 LM1117IMPX-3.3 real image949 LM1117IMPX-3.3 real image950 LM1117IMPX-3.3 Real Image1 LM1117IMPX-3.3 Real Image2 LM1117IMPX-3.3 Real Image3 LM1117IMPX-3.3 Real Image4 LM1117IMPX-3.3 Real Image5 LM1117IMPX-3.3 Real Image6 LM1117IMPX-3.3 Real Image7 LM1117IMPX-3.3 Real Image8
Same model may have multiple batches, images only for reference.
LM1117IMPX-3.3 Texas Instruments LM1117IMPX-3.3 Real Image LM1117IMPX-3.3 real image948 LM1117IMPX-3.3 real image949 LM1117IMPX-3.3 real image950 LM1117IMPX-3.3 Real Image1 LM1117IMPX-3.3 Real Image2 LM1117IMPX-3.3 Real Image3 LM1117IMPX-3.3 Real Image4 LM1117IMPX-3.3 Real Image5 LM1117IMPX-3.3 Real Image6 LM1117IMPX-3.3 Real Image7 LM1117IMPX-3.3 Real Image8
LM1117IMPX-3.3 Texas Instruments LM1117IMPX-3.3 Real Image LM1117IMPX-3.3 real image948 LM1117IMPX-3.3 real image949 LM1117IMPX-3.3 real image950 LM1117IMPX-3.3 Real Image1 LM1117IMPX-3.3 Real Image2 LM1117IMPX-3.3 Real Image3 LM1117IMPX-3.3 Real Image4 LM1117IMPX-3.3 Real Image5 LM1117IMPX-3.3 Real Image6 LM1117IMPX-3.3 Real Image7 LM1117IMPX-3.3 Real Image8
Same model may have multiple batches, images only for reference.

LM1117IMPX-3.3

Part No LM1117IMPX-3.3
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 3.3V 0.8A SOT223
Datasheet
LM1117IMPX-3.3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 15V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 1.2V @ 800mA
Output Current 800mA
Operating Supply Current 5mA to 10mA
PSRR 75dB (120Hz)
Control Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 1.2V @ 800mA
Mounting SMD (SMT)
Case / Package SOT-223-4
Win Source Part Number 092210-LM1117IMPX-3.3
Family Name LM1117
Introduction Date October 01, 2002
ECCN EAR99
Country of Origin Malaysia
Halogen Free Not Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial, Portable Devices, Consumer Electronics, Power Management
Family Name LM1117I
Ultra Librarian 3D Model Ultra Librarian LM1117IMPX-3.3 CAD Model

Description

The LM1117IMPX-3.3 is a highly efficient, low-dropout voltage regulator from Texas Instruments, a renowned global semiconductor company known for its innovative, high-quality products.

  • Output Voltage: 3.3V (precise)
  • Dropout Voltage: Typically 1.2V @ maximum output current
  • Output Current: Up to 800mA
  • Features: Current limiting and thermal shutdown circuitry
  • Quiescent Current: Low
  • Operating Temperature Range: -40°C to 125°C
  • Package: Compact SOT-223
  • Regulation: Excellent line and load regulation
  • Output Voltage (adjustable version): Can be set anywhere between 1.25V and 13.8V with the use of two external resistors
