LM1117IMPX-5.0/NOPB Real Image LM1117IMPX-5.0/NOPB real image LM1117IMPX-5.0/NOPB real image954 LM1117IMPX-5.0/NOPB Real Image1 LM1117IMPX-5.0/NOPB Real Image2 LM1117IMPX-5.0/NOPB Real Image3 LM1117IMPX-5.0/NOPB Real Image4
Same model may have multiple batches, images only for reference.
LM1117IMPX-5.0/NOPB Real Image LM1117IMPX-5.0/NOPB real image LM1117IMPX-5.0/NOPB real image954 LM1117IMPX-5.0/NOPB Real Image1 LM1117IMPX-5.0/NOPB Real Image2 LM1117IMPX-5.0/NOPB Real Image3 LM1117IMPX-5.0/NOPB Real Image4
LM1117IMPX-5.0/NOPB Real Image LM1117IMPX-5.0/NOPB real image LM1117IMPX-5.0/NOPB real image954 LM1117IMPX-5.0/NOPB Real Image1 LM1117IMPX-5.0/NOPB Real Image2 LM1117IMPX-5.0/NOPB Real Image3 LM1117IMPX-5.0/NOPB Real Image4
Same model may have multiple batches, images only for reference.

LM1117IMPX-5.0/NOPB

Part No LM1117IMPX-5.0/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V 0.8A SOT223
Datasheet
LM1117IMPX-5.0/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 15V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 1.2V @ 800mA
Output Current 800mA
Operating Supply Current 5mA to 10mA
PSRR 75dB (120Hz)
Control Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 1.2V @ 800mA
Mounting SMD (SMT)
Case / Package SOT-223-4
Win Source Part Number 018646-LM1117IMPX-5.0/NOPB
Family Name LM1117
Introduction Date June 01, 1998
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management
Ultra Librarian 3D Model Ultra Librarian LM1117IMPX-5.0/NOPB CAD Model

Description

The LM1117IMPX-5.0/NOPB is a high-quality, high-performance voltage regulator designed and manufactured by Texas Instruments.

  • Output: Fixed output, low-dropout linear regulator (LDO)
  • Maximum Output Current: 800mA
  • Output Voltage: 5V
  • Dropout Voltage: Low
  • Protection: Over-temperature and over-current protection mechanisms
  • Package: Compact SOT-223
  • Compliance: RoHS compliant and lead-free
  • Designation: NOPB designation indicates that it is not for reprocessing
