LM1117IMPX-ADJ/NOPB

Name: LM1117IMPX-ADJ/NOPB
Brand: Texas Instruments
SKU: 181073
Availability: InStock
Rating: 4.85 (248 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	LM1117IMPX-ADJ/NOPB
Manufacturer	Texas Instruments
Catalog	PMIC - Voltage Regulators - Linear
Description	IC REG LDO ADJ 0.8A SOT223 / LDO Regulator Pos 1.25V to 13.8V 0.8A 4-Pin(3+Tab) SOT-223 T/R
Datasheet	LM1117IMPX-ADJ/NOPB Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Output Type	Adjustable
Number of Regulators	1
Maximum Input Voltage	15V
Nominal Output Voltage (Min/Fixed)	1.25V
Maximum Output Voltage	13.8V
Dropout Voltage-Max	1.2V @ 800mA
Output Current	800mA
Operating Supply Current	5mA to 10mA
PSRR	75dB (120Hz)
Control Protection Features	Over Current, Over Temperature
Temperature Range - Operating	-40°C to 125°C
Regulator Topology	Positive Adjustable
Output Voltage	1.25 V to 13.8 V
Voltage - Dropout (Typical)	1.2V @ 800mA
Mounting	SMD (SMT)
Case / Package	SOT-223-4
Win Source Part Number	018647-LM1117IMPX-ADJ/NOPB
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	LM1117
Introduction Date	October 15, 2003
ECCN	EAR99
Country of Origin	China, Malaysia
Halogen Free	Compliant
Estimated EOL Date	2031
Ultra Librarian 3D Model	Ultra Librarian LM1117IMPX-ADJ/NOPB CAD Model

Alternative Products

Description

The LM1117IMPX-ADJ/NOPB from Texas Instruments is a high-performance, adjustable output low-dropout linear regulator.

Output Voltage Range: Adjustable from 1.25V to 13.8V
Dropout Voltage: 1.2V @ up to 800mA of output current
Output Voltage Accuracy: Within 1.5%
Efficiency: High efficiency of operation
Protection Features: Current limit and thermal shutdown
Package: Small, surface-mountable SOT-223
Operating Temperature Range: -40°C to 125°C
