The LM25085MM/NOPB is a highly integrated, efficient, small form-factor switching regulator from Texas Instruments designed for a wide range of applications. This device is part of the LM25085 series, which are PWM (Pulse Width Modulation) step-down switching regulators featuring intelligent current limit and a robust thermal shutdown system to enhance overall system reliability and performance.

Key Features:

• Input Voltage Range: The LM25085MM/NOPB operates from a 4.5V to 42V input, making it suitable for a variety of industrial and automotive applications.
• Output Current: It can deliver up to 2.5A of continuous output current to the load.
• Switching Frequency: The device features an adjustable switching frequency from 50 kHz to 1 MHz, allowing flexibility in optimizing inductor size and efficiency.
• Efficiency: High efficiency is achieved through an integrated 170 mΩ N-Channel MOSFET switch and optimized gate driver circuitry.
• Protection Features: It includes overcurrent protection, thermal shutdown, undervoltage lockout, and pre-bias startup capability, ensuring safe operation under abnormal conditions.
• Small Package: Available in a compact 10-pin VSSOP (MSOP) package, the LM25085MM/NOPB is ideal for space-constrained applications.

Applications:

• Automotive systems
• Industrial power systems
• Telecommunications equipment
• Point of Load (POL) power supplies
• Distributed power systems

The LM25085MM/NOPB is a versatile power management solution that combines advanced features and durable design to meet the stringent requirements of modern electronic devices. With its wide input voltage range, high output current capability, and comprehensive protection features, this regulator ensures a reliable power supply for your critical applications. Whether you're designing for automotive, industrial, or communication environments, the LM25085MM/NOPB from Texas Instruments is a reliable choice for your power conversion needs.
