Introducing the Texas Instruments LM27761DSGT

The LM27761DSGT from Texas Instruments is a highly integrated, low-noise regulated charge pump DC-DC converter that is designed to meet the requirements of space-constrained and noise-sensitive applications. This advanced power solution offers a unique combination of features that make it ideal for powering noise-sensitive circuitry in portable devices such as smartphones, tablets, and medical equipment.

Key Features

• Low-Noise Operation: The LM27761DSGT utilizes a regulated charge pump to generate a low-noise negative voltage from a positive input voltage. This feature significantly reduces the ripple and noise typically associated with charge pumps, making it perfect for precision analog circuits.
• Wide Input Voltage Range: It operates over a wide input voltage range from 2.7V to 5.5V, accommodating a variety of power sources and ensuring compatibility with most battery technologies.
• Adjustable Output Voltage: The output voltage is adjustable via external resistors, giving designers the flexibility to set the voltage to a desired level, within the range of -1.5V to -5.5V.
• High Efficiency: The device features high efficiency over a wide load current range, which not only extends battery life but also minimizes heat generation within the system.
• Small Package Size: Available in a compact WSON package, the LM27761DSGT is designed for space-saving on PCBs, a critical factor in miniaturized electronic devices.

Applications

The LM27761DSGT is suitable for a wide range of applications where a negative supply voltage is required, including but not limited to:

• Organic LED (OLED) Display Bias
• Operational Amplifier Power Supplies
• Audio Circuitry
• Sensor Biasing
• Portable Medical Devices

With its combination of low noise performance, flexibility, and compact form factor, the Texas Instruments LM27761DSGT is a versatile solution that enhances the performance and reliability of your sensitive electronic applications. The device's robust design ensures a smooth and stable power supply, making it a go-to choice for designers looking to optimize their power management systems.
