LM2940T-5.0 Real Image LM2940T-5.0 real image1240 LM2940T-5.0 Real Image1 LM2940T-5.0 Real Image2 LM2940T-5.0 Real Image3 LM2940T-5.0 Real Image4
Same model may have multiple batches, images only for reference.
LM2940T-5.0 Real Image LM2940T-5.0 real image1240 LM2940T-5.0 Real Image1 LM2940T-5.0 Real Image2 LM2940T-5.0 Real Image3 LM2940T-5.0 Real Image4
LM2940T-5.0 Real Image LM2940T-5.0 real image1240 LM2940T-5.0 Real Image1 LM2940T-5.0 Real Image2 LM2940T-5.0 Real Image3 LM2940T-5.0 Real Image4
Same model may have multiple batches, images only for reference.

LM2940T-5.0

Part No LM2940T-5.0
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V 1A TO220-3
Datasheet
LM2940T-5.0 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 26V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 1V @ 1A
Output Current 1A
Operating Supply Current 10mA to 15mA
PSRR 64dB (120Hz)
Control Protection Features Over Current, Over Temperature, Reverse Polarity, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 0.5V @ 1A
Mounting Through Hole
Case / Package TO-220-3
Win Source Part Number 090789-LM2940T-5.0
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM2940T-5.0 CAD Model

Description

The LM2940T-5.0 is a low dropout voltage regulator manufactured by Texas Instruments, a renowned American technology company that designs and manufactures semiconductors and other integrated circuits.

  • Output Voltage: 5.0 volts
  • Voltage Regulator: Positive
  • Current: up to 1 A
  • Dropout characteristic: Low
  • Protection features: Internal current limiting and thermal shutdown
  • Package: TO-220
