The LM317AMDTX from Texas Instruments is a versatile and reliable adjustable voltage regulator designed for a wide range of applications. This three-terminal positive regulator is capable of supplying more than 1.5A over an output voltage range of 1.25V to 37V. It features an adjustable output that allows for the setting of the output voltage with just two external resistors, making it a flexible solution for custom voltage requirements.

Key Features

• Output Voltage Range: Adjustable from 1.25V to 37V, allowing for a wide range of applications and customizations.
• Output Current: Capable of delivering 1.5A of load current with sufficient heat sinking, making it suitable for moderate to high current applications.
• Thermal Overload Protection: Ensures the device remains safe under extreme operating conditions by shutting down to prevent overheating.
• Current Limiting: Built-in current limiting protects the regulator and the load from fault conditions like output short circuits.
• Package: Available in the TO-252 (DPAK) package, which is suitable for surface-mount technology and offers a compact footprint for space-constrained applications.

Applications

The LM317AMDTX is highly versatile and can be used in a variety of electronic circuits and systems. It is commonly employed in power supplies, battery chargers, and as a post-regulator for switching supplies. Its capability to provide a custom voltage makes it ideal for research and development projects where standard voltage levels are not suitable. Additionally, it is often found in consumer electronics, automotive projects, and hobbyist applications where voltage regulation is required.

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the LM317AMDTX is no exception. It is designed to meet the rigorous standards of the industry, ensuring reliability and performance. The device's robust design and protection features make it a dependable choice for both commercial and industrial applications.

For detailed specifications, application notes, and additional resources, please refer to the official Texas Instruments datasheet for the LM317AMDTX adjustable voltage regulator.
