LM317HVT Real Image LM317HVT real image1296 LM317HVT real image1297 LM317HVT Real Image1 LM317HVT Real Image2 LM317HVT Real Image3 LM317HVT Real Image4 LM317HVT Real Image5 LM317HVT Real Image6 LM317HVT Real Image7 LM317HVT Real Image8
Same model may have multiple batches, images only for reference.
LM317HVT Real Image LM317HVT real image1296 LM317HVT real image1297 LM317HVT Real Image1 LM317HVT Real Image2 LM317HVT Real Image3 LM317HVT Real Image4 LM317HVT Real Image5 LM317HVT Real Image6 LM317HVT Real Image7 LM317HVT Real Image8
LM317HVT Real Image LM317HVT real image1296 LM317HVT real image1297 LM317HVT Real Image1 LM317HVT Real Image2 LM317HVT Real Image3 LM317HVT Real Image4 LM317HVT Real Image5 LM317HVT Real Image6 LM317HVT Real Image7 LM317HVT Real Image8
Same model may have multiple batches, images only for reference.

LM317HVT

Part No LM317HVT
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LINEAR ADJ 1.5A TO220-3
Datasheet
LM317HVT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 60V
Nominal Output Voltage (Min/Fixed) 1.25V
Maximum Output Voltage 57V
PSRR 80dB to 65dB (120Hz)
Control Protection Features Over Circuit, Over Temperature, Short Circuit
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.25 V to 57 V
Mounting Through Hole
Case / Package TO-220-3
Win Source Part Number 83031-LM317HVT
Family Name LM317HV
Introduction Date June 01, 2001
ECCN EAR99
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM317HVT CAD Model

Description

The LM317HVT from Texas Instruments is an adjustable voltage regulator that offers exceptional performance and functionality.

  • Load Current: more than 1.5A
  • Output Voltage: adjustable over a 1.2 to 37V range
  • Type: three-terminal positive regulator
  • Output Current: 1.5A
  • Line and Load Regulation: superior
  • Thermal Regulation: excellent
  • Thermal Overload Protection: built-in
  • Current Limit Constant: with temperature
  • Adjustability: The output voltage can be set to any value between 1.2V and 37V by using two external resistors
  • Operating Temperature Range: -40°C to 125°C
