LM3478MM Real Image LM3478MM real image1398 LM3478MM real image1399 LM3478MM Real Image1 LM3478MM Real Image2 LM3478MM Real Image3 LM3478MM Real Image4 LM3478MM Real Image5
Same model may have multiple batches, images only for reference.
LM3478MM Real Image LM3478MM real image1398 LM3478MM real image1399 LM3478MM Real Image1 LM3478MM Real Image2 LM3478MM Real Image3 LM3478MM Real Image4 LM3478MM Real Image5
LM3478MM Real Image LM3478MM real image1398 LM3478MM real image1399 LM3478MM Real Image1 LM3478MM Real Image2 LM3478MM Real Image3 LM3478MM Real Image4 LM3478MM Real Image5
Same model may have multiple batches, images only for reference.

LM3478MM

Part No LM3478MM
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Controllers
Description IC REG CTRLR MULT TOP 8VSSOP
Datasheet
LM3478MM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Transistor Driver
Purpose Step-Up, Step-Up/Step-Down
Topology Boost, Flyback, SEPIC
Number of Outputs 1
Output Phases 1
Supply Voltage - Operating 2.97 V to 40 V
Frequency - Switching 100kHz to 1MHz
Duty Cycle (Max) 100%
Synchronous Rectifier No
Clock Sync No
Control Features Enable, Frequency Control
Temperature Range - Operating -40°C to 125°C (TJ)
Case / Package 8-VSSOP
Win Source Part Number 091962-LM3478MM
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Communications & Networking, Automotive
Family Name LM3478
Introduction Date September 01, 2001
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian LM3478MM CAD Model

Description

The LM3478MM is a versatile, high-performance product from the renowned technology company, Texas Instruments.

  • Description: Low-side power N-channel MOSFET controller
  • Operating Frequency: Operates at a switching frequency of up to 600 kHz
  • Input Voltage Range: 2.97V to 40V
  • Operating Modes: Operates in both continuous and discontinuous modes
  • Reference Voltage: Precision reference voltage of 1.265V
  • Safety Features: Thermal shutdown, under-voltage lockout, and current limit
  • Package: 8-pin MSOP package
  • Applications: power supplies for digital cameras, DSL modems, battery chargers, and power adapters
