LM5105SD/NOPB Real Image LM5105SD/NOPB Real Image1 LM5105SD/NOPB Real Image2
Same model may have multiple batches, images only for reference.
LM5105SD/NOPB Real Image LM5105SD/NOPB Real Image1 LM5105SD/NOPB Real Image2
LM5105SD/NOPB Real Image LM5105SD/NOPB Real Image1 LM5105SD/NOPB Real Image2
Same model may have multiple batches, images only for reference.

LM5105SD/NOPB

Part No LM5105SD/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Gate Drivers
Description IC DVR GATE HALF BRIDGE 10WSON
Datasheet
LM5105SD/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Driven Configuration Half-Bridge
Channel Type Synchronous
Number of Drivers 2
Gate Type N-Channel MOSFET
Supply Voltage - Operating 8 V to 14 V
Logic Voltage - VIL, VIH 0.8V, 2.2V
Current - Peak Output (Source, Sink) 1.8A, 1.8A
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 118V
Rise and Fall Time 15ns, 15ns
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 10-WSON (4x4)
Win Source Part Number 140872-LM5105SD/NOPB
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM5105SD/NOPB CAD Model

Description

The LM5105SD/NOPB is a high-voltage, high-speed, half-bridge gate driver manufactured by Texas Instruments.

  • Supply Voltages: Up to 100V
  • Output Stages Current: 2A
  • Package: 10-pin LLP
