LM5118MH/NOPB Real Image LM5118MH/NOPB Real Image1 LM5118MH/NOPB Real Image2 LM5118MH/NOPB Real Image3
LM5118MH/NOPB Real Image LM5118MH/NOPB Real Image1 LM5118MH/NOPB Real Image2 LM5118MH/NOPB Real Image3
Same model may have multiple batches, images only for reference.

LM5118MH/NOPB

Part No LM5118MH/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Controllers
Description IC REG CTRLR BCK/BCK-BST 20TSSOP
Datasheet
LM5118MH/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Output Type Transistor Driver
Purpose Step-Down, Step-Up/Step-Down
Topology Buck, Buck-Boost
Number of Outputs 1
Output Phases 1
Supply Voltage - Operating 3 V to 75 V
Frequency - Switching 200kHz, 515kHz
Duty Cycle (Max) 80%
Synchronous Rectifier No
Clock Sync Yes
Control Features Enable, Frequency Control, Ramp, Soft Start
Temperature Range - Operating -40°C to 125°C (TJ)
Case / Package 20-HTSSOP
Win Source Part Number 085323-LM5118MH/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM5118MH/NOPB CAD Model

Description

The LM5118MH/NOPB from Texas Instruments is an advanced and versatile voltage regulator designed to manage power in a wide range of applications.

  • Input Voltage Range: 5.5V to 75V
  • Output Voltage: 1.215V to 75V
  • Topology: Four-switch synchronous rectification buck-boost
  • Protection Features: Cycle-by-cycle current limit, thermal shutdown, and an adjustable undervoltage lockout
  • Package: Thermally enhanced 20-pin HTSSOP PowerPAD
  • Ease of Use Features: Programmable soft-start, frequency synchronization, and tracking capability
  • Shutdown Current: 10µA
