LM5118Q1MH/NOPB Real Image LM5118Q1MH/NOPB Real Image
Same model may have multiple batches, images only for reference.
LM5118Q1MH/NOPB Real Image LM5118Q1MH/NOPB Real Image
LM5118Q1MH/NOPB Real Image LM5118Q1MH/NOPB Real Image
Same model may have multiple batches, images only for reference.

LM5118Q1MH/NOPB

Part No LM5118Q1MH/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Controllers
Description IC REG CTRLR BCK/BCK-BST 20TSSOP
Datasheet
LM5118Q1MH/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Output Type Transistor Driver
Purpose Step-Down, Step-Up/Step-Down
Topology Buck, Buck-Boost
Number of Outputs 1
Output Phases 1
Supply Voltage - Operating 3 V to 75 V
Frequency - Switching 200kHz, 515kHz
Duty Cycle (Max) 80%
Synchronous Rectifier No
Clock Sync Yes
Control Features Enable, Frequency Control, Ramp, Soft Start
Temperature Range - Operating -40°C to 125°C (TJ)
Case / Package 20-HTSSOP
Win Source Part Number 206424-LM5118Q1MH/NOPB
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM5118Q1MH/NOPB CAD Model

Description

The LM5118Q1MH/NOPB is a versatile, high-performance product from Texas Instruments, a renowned leader in semiconductor technology.

  • Input Voltage Range: 3V to 75V
  • Control Circuit: High-performance buck-boost control circuit (seamless transitions between buck, buck-boost, and boost modes)
  • Switching Frequency: Adjustable switching frequency, ranging from 50kHz to 500kHz
  • Synchronization: Frequency synchronization input (enables synchronization to an external clock)
  • Protection: Cycle-by-cycle current limit, thermal shutdown, and an under-voltage lockout
  • Package: 20-pin TSSOP PowerPAD package
  • Qualification: AEC-Q100 qualified
  • Compliance: RoHS compliant
