LM53603AQPWPRQ1

Part No LM53603AQPWPRQ1
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG BUCK ADJ 3A 16HTSSOP / Buck Switching Regulator IC Positive Adjustable 3.3V 1 Output 3A 16-TSSOP (0.173", 4.40mm Width) Exposed Pad
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - DC DC Switching Regulators
Mfr Texas Instruments
Series Automotive, AEC-Q100
Package Tape & Reel
Product Status Active
Function Step-Down
Output Configuration Positive
Topology Buck
Output Type Adjustable
Number of Outputs 1
Voltage - Input (Min) 3.9V
Voltage - Input (Max) 36V
Voltage - Output (Min/Fixed) 3.3V
Voltage - Output (Max) 6V
Current - Output 3A
Frequency - Switching 2.1MHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package 16-HTSSOP
Base Product Number LM53603
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1353404-LM53603AQPWPRQ1
Ultra Librarian 3D Model Ultra Librarian LM53603AQPWPRQ1 CAD Model

Description

The LM53603AQPWPRQ1 is a high-performance automotive-grade step-down converter designed and manufactured by Texas Instruments. This advanced power management integrated circuit (IC) is specifically engineered to meet the rigorous demands of automotive applications, providing a reliable and efficient power supply solution.

Key Features

  • Wide Input Voltage Range: The device operates from an input voltage range of 3.5V to 36V, making it suitable for handling various levels of power supply fluctuations commonly found in automotive environments.
  • High-Efficiency Synchronous Buck Converter: With its synchronous buck topology, the LM53603AQPWPRQ1 offers high efficiency, which is crucial for reducing thermal load and improving system performance.
  • Adjustable Output Voltage: The output voltage can be adjusted to meet the requirements of specific applications, ensuring versatility and broad compatibility with different automotive systems.
  • Robust Thermal Performance: Designed with thermal performance in mind, it can operate in a wide temperature range, maintaining functionality even under harsh conditions.
  • EMI Compliance: The device is designed to meet CISPR 25 Class 5 radiated emissions standards, ensuring minimal electromagnetic interference in sensitive automotive electronics.

Applications

The LM53603AQPWPRQ1 is ideally suited for a variety of automotive applications, including infotainment systems, advanced driver-assistance systems (ADAS), and other vehicle electronics that require stable and efficient power supply solutions.

Quality and Reliability

As an AEC-Q100 qualified device, the LM53603AQPWPRQ1 meets the stringent quality standards required for automotive components. Texas Instruments' commitment to quality ensures that this power converter provides reliable performance over the lifespan of the vehicle.

Package and Availability

The device is offered in a 16-pin HTSSOP package with PowerPAD™ for enhanced thermal dissipation. Its compact form factor and surface-mount design make it easy to integrate into various automotive electronic assemblies. For pricing, samples, and ordering information, customers can visit the Texas Instruments website or contact authorized distributors.
