LM7301IM5X/NOPB

Part No LM7301IM5X/NOPB
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 4MHZ RRO SOT23-5
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 1
Output Type Rail-to-Rail
Slew Rate 1.25 V/μs
Gain Bandwidth Product (GBP) 4MHz
Current - Input Bias 103nA
Voltage - Input Offset 40μV
Operating Supply Current 720μA
Channel Output Current 11.7mA
Supply Voltage - Operating 1.8 V to 32 V, ±0.9 V to 16 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 019429-LM7301IM5X/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Portable Devices, Signal Processing, Communications & Networking
Family Name LM7301
Introduction Date November 15, 2002
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian LM7301IM5X/NOPB CAD Model

Description

The LM7301IM5X/NOPB from Texas Instruments is a high-performance, general-purpose operational amplifier designed with advanced technology to offer superior functionality and enhanced performance for a wide range of applications.

  • Power Requirement: The LM7301IM5X/NOPB operates with a single supply voltage range of 2.7V to 32V or a dual supply voltage range of ±1.35V to ±16V. This wide operating voltage range makes it a versatile choice for various applications.
  • Speed and Accuracy: The LM7301IM5X/NOPB features a high slew rate of 10V/µs and a high gain-bandwidth product of 4.5MHz, ensuring fast and accurate signal amplification and processing. It also has a low input bias current of 1pA, minimizing errors in high impedance applications, and rail-to-rail input and output, allowing for maximum possible swing within the supply voltage range, thus increasing the dynamic range and precision.
  • RoHS Compliance: The LM7301IM5X/NOPB is designed for applications that require high-speed and low-distortion amplification, such as audio and video processing, telecommunications, and instrumentation. It is available in a small SOT-23 package, which saves board space and allows for high-density circuit designs. The LM7301IM5X/NOPB also features a wide operating temperature range of -40°C to +125°C, making it suitable for use in harsh environments. As a product of Texas Instruments, it is RoHS compliant and lead-free, adhering to the highest environmental and safety standards.
