LM7322MM/NOPB

Part No LM7322MM/NOPB
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description High Output Current and Unlimited Capacitive Load Operational Amplifier
Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Amplifier Type General
Number of Circuits 2
Output Type Rail-to-Rail
SR - Slew Rate 18 V/μs
GBP - Gain Bandwidth Product 20MHz
Current - Input Bias 1.1μA
Voltage - Input Offset 700μV
Operating Supply Current 2.5mA
Output Current per Channel 100mA
Dual Supply Voltage (±) 2.5 V ~ 32 V, ±1.25 V ~ 16 V
Operating Temperature Range -40°C ~ 125°C
Mounting SMD
Package 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Manufacturer Package 8-VSSOP
Win Source Part Number 1200652-LM7322MM/NOPB
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name LM7322
Introduction Date May 28, 2008
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian LM7322MM/NOPB CAD Model

Description

Product Overview: LM7322MM/NOPB

The LM7322MM/NOPB is a high-performance, dual operational amplifier (op-amp) from Texas Instruments, designed for a wide range of applications. This op-amp is part of the LM7322 series and is known for its high speed, low power consumption, and wide bandwidth. It operates with a supply range from 2.7V to 12V and can deliver a continuous output current of up to 30mA, making it suitable for both single-supply and split-supply operations.

Key Features

  • High Speed: The LM7322MM/NOPB offers a slew rate of 20 V/μs and a gain bandwidth product of 20 MHz, which makes it ideal for fast signal processing applications.
  • Low Power Consumption: Its low supply current of 2.7 mA per channel is beneficial for power-sensitive designs.
  • Rail-to-Rail Output: The op-amp provides rail-to-rail output swing, which maximizes the dynamic range in low voltage applications.
  • Wide Temperature Range: With an operating temperature range of -40°C to +125°C, it is suitable for industrial and automotive applications that require reliable performance under harsh conditions.

Applications

The LM7322MM/NOPB is versatile and can be used in various applications, including:

  • Active filters
  • ADC buffer amplifiers
  • DAC current-to-voltage converters
  • Audio and video signal processing
  • Telecommunications
  • Test and measurement equipment

Quality and Reliability

Texas Instruments is committed to delivering high-quality products. The LM7322MM/NOPB comes in an 8-pin VSSOP package and is RoHS compliant. It is also characterized for enhanced product-life reliability, ensuring long-term performance in a variety of applications.

Ordering Information

For ordering and detailed technical information, including datasheets, reference designs, and evaluation modules, visit the Texas Instruments website or contact your local TI distributor. The part number LM7322MM/NOPB ensures that you receive the no-lead (NOPB) version of the LM7322 series, in line with environmentally friendly manufacturing practices.
