Same model may have multiple batches, images only for reference.

LM78L05ACMX

Name: LM78L05ACMX
Brand: Texas Instruments
SKU: 185859
Availability: InStock
Rating: 4.85 (489 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	LM78L05ACMX
Manufacturer	Texas Instruments
Catalog	PMIC - Voltage Regulators - Linear
Description	IC REG LDO 5V 0.1A 8SOIC
Datasheet	LM78L05ACMX Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Output Type	Fixed
Number of Regulators	1
Maximum Input Voltage	35V
Nominal Output Voltage (Min/Fixed)	5V
Output Current	100mA
Operating Supply Current	3mA
PSRR	62dB (120Hz)
Control Protection Features	Over Temperature, Short Circuit
Temperature Range - Operating	0°C to 125°C
Regulator Topology	Positive Fixed
Output Voltage	5V
Mounting	SMD (SMT)
Case / Package	8-SOIC
Win Source Part Number	093326-LM78L05ACMX
Family Name	LM78L05
Introduction Date	February 01, 1995
ECCN	EAR99
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	2027
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Power Management
Ultra Librarian 3D Model	Ultra Librarian LM78L05ACMX CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor LM78L05ACZ is a fixed voltage regulator IC that provides a fixed 5V output voltage.

Output Voltage: 5V
Input Voltage Range: Up to 30V
Output Current: 100mA
Forward Voltage: 1.25V @ 150mA
Reverse Recovery Time: 4ns
Current Reverse Leakage: 500nA @ 80V
Thermal Protection: Over-temperature and short-circuit protection
Package: TO-92-3
