LM8272MM Real Image LM8272MM real image1693 LM8272MM real image1694 LM8272MM Real Image1 LM8272MM Real Image2 LM8272MM Real Image3 LM8272MM Real Image4
Same model may have multiple batches, images only for reference.
LM8272MM Real Image LM8272MM real image1693 LM8272MM real image1694 LM8272MM Real Image1 LM8272MM Real Image2 LM8272MM Real Image3 LM8272MM Real Image4
LM8272MM Real Image LM8272MM real image1693 LM8272MM real image1694 LM8272MM Real Image1 LM8272MM Real Image2 LM8272MM Real Image3 LM8272MM Real Image4
Same model may have multiple batches, images only for reference.

LM8272MM

Part No LM8272MM
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 15MHZ RRO 8VSSOP
Datasheet
LM8272MM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Output Type Rail-to-Rail
Slew Rate 15 V/μs
Gain Bandwidth Product (GBP) 15MHz
-3db Bandwidth 12.5MHz
Current - Input Bias 2μA
Voltage - Input Offset 700μV
Operating Supply Current 1.9mA
Channel Output Current 65mA
Supply Voltage - Operating 2.5 V to 24 V, ±1.25 V to 12 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-VSSOP
Win Source Part Number 082858-LM8272MM
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Signal Processing, Sensing & Instrumentation
Family Name LM8272
Introduction Date October 01, 2000
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian LM8272MM CAD Model

Description

The is a high-performance operational amplifier from Texas Instruments, a global semiconductor technology leader.

  • Supply Voltage Range: 2.7V to 5.5V
  • Slew Rate: 20V/µs
  • Input Bias Current: Low
  • Input Offset Voltage: 3mV
  • Package: 8-pin VSSOP
  • Applications: Audio processing, active filters, signal conditioning
  • Environmental Compliance: RoHS
  • Protection: ESD and thermal shutdown
