The Texas Instruments LMH0387SL is a state-of-the-art, high-performance 3G/HD/SD SDI configurable I/O adaptive cable equalizer and cable driver, designed to support a wide range of digital video applications. This advanced semiconductor product is an ideal solution for broadcast video systems, ensuring high-quality signal transmission over long distances and through various media types.

Key Features

• Supports SMPTE 424M, SMPTE 292M, and SMPTE 259M standards, making it versatile for different digital video formats.
• Integrated cable driver and equalizer functionalities allow for straightforward signal conditioning in video applications.
• Adaptive cable equalization capabilities provide extended reach over coaxial cable, optimizing signal integrity for various cable lengths.
• Programmable output swing and pre-emphasis levels to compensate for different cable types and signal losses.
• Low power consumption design, which is crucial for minimizing heat generation and power usage in video equipment.
• Supports data rates up to 2.97 Gbps, ensuring compatibility with high-definition video signals.
• Operates over an industrial temperature range, making it suitable for use in various environments.

Applications

The LMH0387SL is commonly employed in professional video equipment such as video routers, switchers, cameras, and digital signage systems. Its robust design and high data rate support make it an excellent choice for any application that requires reliable, high-quality video signal transmission.

Technical Specifications

This product is available in a space-saving 16-pin WQFN package, offering a compact solution for tight PCB layouts. With its integrated power management and signal conditioning features, the LMH0387SL minimizes the need for external components, simplifying design and reducing system costs.

Ordering and Availability

The LMH0387SL is available for ordering directly from Texas Instruments or through authorized distributors. Detailed documentation, including datasheets, application notes, and design resources, can be found on the Texas Instruments website to assist in the integration of this product into your designs.
